TPLINK Flex Bridge 5 Omada 5 GHz 867 Mbps Long-Range Connectivity for Indoors/Outdoors Wireless Flex Bridge

Works with Flex & Sector bridges for Point-to-Point/Multipoint Bridging: Supports bridging between Flex Bridges, optimized for 8 nodes, and up to 32 with a Sector Bridge hub.* Long-Range 5 GHz 867Mpbs Wireless Bridging up to 3.1 miles: Ideal for extending networks across buildings and remote locations.△ Powering Surveillance with 2 x PoE Out Ports: Features 3 Gigabit PoE ports, including 2 PoE Out ports, easily powering IP cameras and simplifying surveillance network expansion. Role & DIP Switches for Simple Pairing: Seamless role switching with DIP switch for rapid bridge pairing. Reduces configuration and deployment complexity. Easy Alignment with Ball-Joint & Versatile Installation: Flexible wall and pole mounting with an optional ball-joint, allows for quick angle adjustment and fast deployments. Industry-Leading IP66 Weatherproof: IP66 weatherproof and 6 kV lightning protection safeguard your network in harsh outdoor environments.** Flexible Power Supply Options: Supports 802.3at/af, Passive PoE (54V passive PoE adapter included), and 12V DC, allowing flexible power supply via a PoE switch, the included passive PoE adapter, or solar power. App-Guided Alignment for Optimal Performance: Simply bridge alignment with real-time signal strength visualization on the Omada app. Remote Monitoring with Standalone & SDN Management: Use the Omada app for easy on-site setup-no internet required. For added flexibility, switch to Omada SDN, enabling cloud management via the Omada app or web portal for seamless control, and monitor from anywhere.†

HARDWARE FEATURES Interface 3× Gigabit Ethernet Ports (2 Support PoE Out) Button Reset DIP Switch • Role Switch • Pairing Code Switch Power Supply • 12V DC • 802.3at/af PoE • 24V Passive PoE (54V Passive PoE Adapter Included - For Dry Indoor Use Only) Max. Power Consumption DC: 12W PoE: 26.06W with PoE out Dimensions ( W x D x H ) 8.4 × 2 × 4.7 in (214.2 × 50.8 × 119.8 mm) Antenna • 2.4 GHz: 1 × 1 dBi (peak gain), internal omnidirectional antennas • 5 GHz: 2 × 17 dBi (peak gain), internal directional antennas • Beamwidth: Horizontal 40°, Vertical 18° Weatherproof Enclosure IP66 Mounting Pole and wall mounting (Kits included) Management Features Omada App Yes Restore & Backup Yes Firmware update via Web Yes NTP Yes Centralized Management • Omada Central (Cloud-Based) • Omada Hardware Controller • Omada Software Controller Cloud Access Yes. Require the use of an Omada Controller. Email Alerts Yes LED ON/OFF Control Yes SNMP Yes SSH Yes Web-based Management Yes Zero-Touch Provisioning Yes WIRELESS FEATURES PtP Yes PtMP 8 Maximum Transmission Distance 5,000 m (3.1 mi) Wireless Standards IEEE 802.11 a/n/ac Frequency 5 GHz Signal Rate 5 GHz: Up to 867 Mbps Wireless Functions • MU-MIMO: 5G 2x2 MU-MIMO DL • Multiple SSIDs: 1 • Wireless Statistics • Reboot Schedule • RADIUS Accounting • Static IP/Dynamic IP • Rate Limit • Enable/Disable Wireless Radio • Enable/Disable SSID Broadcast Wireless Security • VLAN • Rogue AP Det
