TP-Link XZ000-G6v 1-Port Gigabit XPON Terminal with VoIP

Gigabit Internet Access: One PON port and one gigabit LAN port provide fast transfer speeds.* XPON Support: EPON + GPON dual mode offers greater flexibility for fiber internet access. VoIP Calls: Supports multiple VoIP accounts and various call features to surpass traditional landlines. Ease of Use: Quick and hassle-free installation with easy setup. Remote Management: Supports the OMCI (ONU Management Control Interface) and TR-069 protocols for centralized configuration and management. HARDWARE FEATURES Wave Length Upstream: 1310 nm Downstream: 1490 nm External Power Supply 9VDC/0.6A Interface 1× PON Port 1× GbE Port 1× Phone Port Button Reset Button Power On/Off Button Dimensions ( W x D x H ) 4.1 × 4.1 × 1.0 in (105 × 105.2 × 24.3 mm) IEEE Standards IEEE 802.3, 802.3u, 802.1p, 802.1Q Data Rates Downstream Speeds: 2.488 Gbps (GPON), 1.25 Gbps (EPON)* Upstream Speeds: 1.244 Gbps (GPON), 1.25 Gbps (EPON)* Optical Module Class B+ Transmitter DFB Laser Receiver Super-TIA Distance 0–20 Km Max GPON Standards ITU-T G.988, G.984.1, G.984.2, G.984.3, G.984.4 SOFTWARE FEATURES Management Features Local management: WebGUI, Telnet Remote management: OMCI, TR-069 Security AES Encryption, Packet Filter based on VLAN Advanced Features Upstream and Downstream FEC Dynamic Bandwidth Allocation(DBA) support NSR/SR Up to 16 T-CONTs and 256 GEM Ports Optical power detection Dying Gasp Terminal Silent mechanism VLAN 802.1Q tag VLAN, VLAN transparent mode/VLAN translation mode/VLAN trunk mode, Authentication based on SN and Password, VLAN Auto Detect IGMP IGMP v1/v2/v3 OTHERS Package Content XPON Terminal XZ000-G6v Power Adapter Quick Installation Guide Environment Operating Temperature: 0℃–40℃ (32℉–104℉) Storage Temperature: -40℃–60℃ (-40℉–140℉) Operating Humidity: 10%–90% non-condensing Storage Humidity: 5%–90% non-condensing Certifications CE, RoHS
