TP-Link VIGI INSIGHT S385PI 8MP 1.65MM Lens Outdoor IR Panoramic Bullet Network Camera

180° Panorama View with Huge Vision 4K (8MP) Ultra HD and IR Range Up to 65.62 ft (20 m)*1 Red-Blue Warning Lights with Stronger Deterrence People & Vehicle Analytics*2 Human & Vehicle Classification Smart Detection Smart Video Enhancement Technology Audio and Alarm Interface Available IP67 Weatherproof and IK10 Vandal Proof H.265+ Compression Technology

CAMERA Image Sensor 1/2.7” Progressive Scan CMOS Shutter Speed 1/3 to 1/10000 s Slow Shutter Yes Minimum Illumination 0.005 Lux; 0 Lux with IR Light Day/Night Mechanism IR Cut Filter Day/Night Switch Unified/ Scheduled/ Auto LENS Type Fixed Focal Lens Focal Length 1.65 mm Aperture F2.0 FOV • Horizontal FOV: 180° • Vertical FOV: 86° • Diagonal FOV: 180° Lens Mount M12 DORI Distance 1.65mm: • D: 144.36 ft (44 m) • O: 60.15 ft (18.33 m) • R: 28.87 ft (8.8 m) • I: 14.44 ft (4.4 m) Angle Adjustment (Manual) Range Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° ILLUMINATOR IR LED • Quantity: 4 • Range: 65.62 ft (20 m)*1 • Wavelength: 850nm Illuminator On/Off Control Auto/Scheduled/Always on/Always off VIDEO Max. Resolution 3840 x 2160 Main Stream • Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

• Resolution: 3840x2160,2560x1440,2304x1296,2048x1280,1920x1080,1280x720

Note: • If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. Sub-Stream • Frame Rate： 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

• Resolution: 848x480,704x576, 640x480, 640x360,352x288, 320x240

• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. Bit Rate Control CBR, VBR Video Compression • Main Stream: H.265+/H.265/H.264+/H.264 • Sub-Stream: H.265/H.264 H.264 Type High Profile H.264+ Main Stream Supported H.265 Type Main Profile H.265+ Main Stream Supported Video Bit Rate • Main Stream: 256 Kbps to 8 Mbps • Sub-Stream: 64 Kbps to 1024 Kbps Image Image Settings • Mirror • Brightness • Contrast • Saturation • Sharpness • Exposure • WDR • White Balance • Prevent Overexposure to Infrared Light • HLC Adjustable by Client Software Image Enhancement BLC/3D DNR/HLC/SmartIR Wide Dynamic Range 120 dB SNR ≥ 52 dB Image Parameters Switch Yes Privacy Mask Up to 4 Masks ROI 4 Regions OSD Setting Yes AUDIO Audio Communication Two-Way Audio Audio Input Built-in Microphone Audio In Interface Audio Output Built-in Speaker Audio Out Interface Audio Compression Yes Audio Sampling Rate 8KHz Environment Noise Filtering Yes Audio Bit Rate 64 Kbps(G.711 alaw) NETWORK Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP ONVIF Yes API Open Network Video Interface (Profile S/T/G) Simultaneous Live View 3 Main Streams & 3 Sub-Streams Client VIGI App, VIGI Security Manager, Web UI, VIGI VMS, VIGI Cloud VMS Web Browser • Google Chrome® 57 and above • Firefox® 52 and above • Safari® 11 and above • Microsoft
