TP-Link Archer C2300 AC2300 Wireless Dual Band Gigabit Router_Refurbished

SECURITY Network Security SPI Firewall Access Control IP & MAC Binding Application Layer Gateway

HomeCare™ Antivirus Malicious Site Checker Port Intrusion Prevention Infected Device Isolation Notification and Log Guest Network 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network VPN Server OpenVPN PPTP WiFi Encryption WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x) WIRELESS Standards Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz WiFi Speeds AC2300 5 GHz: 1625 Mbps (802.11ac) 2.4 GHz: 600 Mbps (802.11n) WiFi Range 3 Bedroom Houses 3× Detachable High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming Concentrates wireless signal strength towards clients to expand WiFi range WiFi Capacity Medium Dual-Band Allocate devices to different bands for optimal performance

3×3 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients

Airtime Fairness Improves network efficiency by limiting excessive occupation Working Modes Router Mode Access Point Mode HARDWARE Processor 1.8 GHz 64 Bit Dual-Core CPU Ethernet Ports 1× Gigabit WAN Port 4× Gigabit LAN Ports

Static Link Aggregation (LAG) available with 2× LAN ports USB Support 1× USB 3.0 Port 1× USB 2.0 Port

Supported Partition Formats: NTFS, exFAT, HFS+, FAT32

Supported Functions: Apple Time Machine FTP Server Media Server Samba Server Buttons Wi-Fi On/Off Button Power On/Off Button LED On/Off Button WPS Button Reset Button Power 12 V ⎓ 2 A SOFTWARE Protocols IPv4 IPv6 Service Kits HomeCare™ Parental Controls HomeCare™ Parental Controls Custom Profiles Content Filtering App Block URL Filtering Time Limit Time Schedule (Bedtime) Log Insight WAN Types Dynamic IP Static IP PPPoE PPTP L2TP Quality of Service QoS by Device

HomeCare™ QoS QoS by Application Cloud Service OTA Firmware Upgrade TP-Link ID DDNS NAT Forwarding Virtual Servers Port Forwarding Port Triggering DMZ UPnP IPTV IGMP Proxy IGMP Snooping Bridge Tag VLAN DHCP Address Reservation DHCP Client List Server DDNS TP-Link NO-IP DynDNS Management Tether App Webpage OTHER System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access) Certifications FCC, CE, RoHS Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing TEST DATA WiFi Transmission Power CE: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <30dBm WiFi Reception Sensitivity 5GHz: 11a 6Mbps: -91dBm 11a 54Mbps: -72dBm 11n HT20: -70dBm 11n HT40: -69dBm 11ac HT20: -60dBm 11ac HT40: -61dBm 11ac HT80: -56dBm 2.4GHz: 11g 54Mbps: -73dBm 11n HT20: -72dBm 11n HT40: -69dBm PHYSICAL Dimensions (W×D×H) 8.5 × 6.5 × 1.4 in (216 × 164 × 36.8 mm) Package Contents Wi-Fi Router Archer C2300 Power Adapter RJ45 Ethernet Cable Quick Installation Guide
