Speedex T9581 8MP/4K 2.8MM Lens IP66 Dome IP Camera

-8MP ( 3840 × 2160 ) H.265 coding

-Max.resolution: 3840 2160

-ICR auto switch, true day / night, ROI coding

-3D DNR, digital WDR, HLC, BLC, Smart IR, defog

-10~20m IR night view distance

-Support smart phone, iPad, remote monitoring

-DC12V/PoE power supply

-P2P function optional

-IP 66 & IK10 ingress protection

-Support three streams

-Smart analytics (optional): object removal detection, abnormal video signal detection, line crossing detection  and region intrusion detection

Model

T9581S2

Camera

Image Sensor

1 / 2.5 "CMOS

Image Size

3840 × 2160

Electronic Shutter

1 / 25 s ~ 1 / 100000 s

Iris Type

Fixed Iris

Min. Illumination

0.068 lux @F2.0, AGC ON; 0 lux with IR

0.024 lux @ F1.2, AGC ON; 0 lux with IR

Lens

3.6 mm @F1.6

Horizontal field of view: 87.7°

Lens Mount

M12

Wide Dynamic Range

Digital WDR

BLC

Yes

HLC

Yes

Defog

Yes

Digital NR

3D DNR

Angle Adjustment

Pan: 0°~355°; Tilt:0°~67°; Rotation: 0°~355°


Video Compression

H.265 / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

8MP ( 3840 × 2160 ), 2K ( 2560 × 1440 ), 3MP ( 2304 × 1296 ),

1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240

Main Stream

60Hz : 8MP(1~20fps)/ 2K(1~30fps)/ 3MP(1~30fps)/

1080P(1~30fps)/ 720P(1~30fps)

50Hz : 8MP(1~20fps)/2K（1~25fps）/3MP（1~25fps）/

1080P（1~25fps）/ 720P（1~25fps）

Sub Stream

60Hz : 1080P/720P/D1(1~30fps); 50HZ:1080P/720P/D1(1~25fps)

Third Stream

60Hz : 720P/D1/CIF/480x240 (1~30fps);

50HZ: 720P/D1/CIF/480x240  (1~25fps)

Bit Rate

128 Kbps ~ 10 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ45

Video Output

No

Audio

No

Storage

No

Hardware Reset

No

Functions

Remote Monitoring

Web browsing,CMS remote control

Online Connection

Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, 802.1x, UPnP, HTTPs, QoS

Interface Protocol

ONVIF, GB-T/28181-2011

Storage

Network remote storage

Smart Alarm

Motion detection

Intelligent Analytics

Region intrusion detection, object removal detection, abnormal video detection and line crossing detection (optional)

General function

Watermark, IP address filtering, video mask, heartbeat, password protection

PoE

Yes

IR Distance

10 ~ 20 m

Ingress Protection

IP 66 & IK10

Others

Power Supply

DC12V/PoE

Power Consumption

< 6W

Operating Environment

- 30 °C ~ 60 °C (-22°
