- 1/3" 4.0Mega progressive scan CMOS
- H.264 H.265 4.0Mega realtime recording
- Support intrusion detection, ROI
- 2D/3D DNR, DWDR, Anti-fog, IR_CUT
- Triple-Stream, Mobile APP, Support P2P
- Support PoE, Support reset, TF Card
- Support ONVIF
- IP66，IK10
Specification Sensor
1/3" 4 Mega progressive scan CMOS
Solution
Hi3516D + OV4689
Min.illumination
Colour:0.1Lux/F1.2; 0Lux/F1.2(IR ON)
Lens
3.3-10.5mm Vari-focusing Lens
IR distance
30 M
Electronic shutter
Auto(1/25s-1/10000s Adjustable)
Day/Night
Auto/Color / B&W (IR_CUT)
Noise Reduction
2D/3D Digital Noise Reduction
Anti-fog
Support
WDR
Digital WDR
Image Adjustment
Sharpness,Brightness,Saturation,Contrast Adjustable
Video Encoding
H.264, H.265
Encoding Type
H.265:MainProfile; H.264:High Profile/Main Profile/BaseLine Profile
Record Resolution
Main Stream: 2560*1440 @ 20fps; Sub Stream: 704*576 @ 20fps; Third Stream:1280*720 @ 15fps
Video Bitrate Control
Support VBR/CBR
Video Bitrate Range
32Kbps ~ 8Mbps
Audio
1 Audio Input; 1 Audio Output
Alarm
1 Alarm input ; 1 Alarm output
Storage
Support Micro SD/TF Card/SDHC/SDXC Card Max 128G
RS485
Support
Reset Button
Front set reset button
CVBS output
Support
Network Interface
RJ45 10M/100M adaptive Ethernet interface
Motion Detection
Multiple detection zones, variable sensitivity levels
ROI
Support
Corridor Mode
Support
Privacy Masking
Four zones for privacy masking
Snapshot
JPEG capture,capture resolution is the max coding resolution
Security Features
Support password protection, watermarking features
Text Overlay
Support (Channel name and time title)
Alarm
Support network anomaly,mask alarm and etc.
Intelligent Function
Support line-crossing detection
Mobile APP
IOS, Andriod
Network Function
TCP/IP; UDP; HTTP; IGMP; ICMP; DHCP; RTP/RTSP; DNS; DDNS; FTP; NTP; PPPOE; UPNP; SMTP
Protocol
Support ONVIF and CGI protocol
Protection Grade
IP66, IK10
PoE
Support
Power
DC 12V
Operation Temperature
-10 ~ +60° C
Operation humidity
10 - 90%
Power supply
8W MAX
Dimensions
154 x 120 (mm)
Weight
1150g
