Hikvision DS-2CD6D54G2-IZHS/NFC 4-Directional Multisensor 360° IP Camera

-4 adjustable lenses in one camera cover up to 360° field of view, ensuring no blind area monitoring and the monitoring tilt angle can be adjusted

-Each lens up to 5 MP, capturing clear images, and more details can be displayed on video wall

-Clear imaging against strong back light due to 120 dB true WDR technology

-Water and dust resistant (IP67) and vandal proof (IK10)

-Human and vehicle target classification based on deep learning for up to 4 channels

-Unique PTRZ capability for efficient installation

-Audio and alarm interface available

Camera Image Sensor 1/2.4" Progressive Scan CMOS Max. Resolution 2560 × 1920 Min. Illumination Color: 0.005 Lux @ (F1.2, AGC ON),B/W: 0.002 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR Shutter Time 1 s to 1/100,000 s Day & Night IR cut filter Angle Adjustment Pan: 0° to 350°,tilt: 0° to 90°,rotate: -90° to 90° Lens Lens Type Varifocal lens, motorized lens, 2.8 to 8 mm Focal Length & FOV 2.8 to 8 mm, horizontal FOV 96.5° to 48.9°, vertical FOV 69.9° to 36.5°, diagonal FOV 129° to 61.3° Lens Mount Ø14 Focus Semi-auto,Manual Aperture F1.9 Illuminator Supplement Light Type IR Supplement Light Range Up to 30 m IR Wavelength 850 nm Video Main Stream

50 Hz: 25 fps (2560× 1920, 2048× 1536, 1920 × 1080, 1280 × 720)

60 Hz: 30 fps (2560× 1920, 2048× 1536, 1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (704 × 576, 640 × 480)

60 Hz: 30 fps (704 × 480, 640 × 480)

Third Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG,

Third stream: H.265/H.264

Video Bit Rate 32 Kbps to 8 Mbps H.264 Type Baseline Profile,Main Profile,High Profile H.265 Type Main Profile Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 4 fixed regions for each stream Target Cropping Yes Audio Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Audio Sampling Rate 8 kHz/16 kHz/32 kHz/48 kHz Environment Noise Filtering Yes Network Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, WebSocket, WebSockets, SSL/TLS Simultaneous Live View Up to 20 channels API Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP User/Host

Up to 32 users

3 user levels: administrator, operator, and user

Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface Network Storage

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

Together with high-end Hikvision memory card, memory card encryption and
