Hikvision DS-2CD6D42G0-IS 4MP Dual-Directional PanoVu Camera

-High quality imaging with 4 MP resolution

-3D DNR technology delivers clean and sharp images

-Supports 2-channel WDR to realize clear imaging against strong back light

-Efficient H.265 compression technology

-Water and dust resistant (IP67) and vandal resistant (IK10)

-Built-in microphone for real-time audio security

-Easy installation with Power over Ethernet (PoE) technology

Camera Image Sensor 1.3" Progressive Scan CMOS Max. Resolution 2688 × 1520 Min. Illumination Color: 0.005 Lux @ (F1.2, AGC ON),B/W: 0.001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR Shutter Time 1 s to 1/100,000 s Day & Night IR cut filter Angle Adjustment Pan: -90° to 90°,tilt: 0 to 60° (2.8 mm),0 to 70° (4/6 mm),rotate: 0° to 355° Lens Focal Length & FOV

2.8 mm, horizontal FOV 98.2°, vertical FOV 54.2°, diagonal FOV 114.6°

4 mm, horizontal FOV 78.8°, vertical FOV 40.5°, diagonal FOV 93.9°

6 mm, horizontal FOV 49.1°, vertical FOV 26.3°, diagonal FOV 57.2°

Lens Mount M12 Aperture F1.6 DORI DORI

2.8 mm: D: 61.1 m, O: 24.2 m, R: 12.2 m, I: 6.1 m

4 mm: D: 85.4 m, O: 33.9 m, R: 17.1 m, I: 8.5 m

6 mm: D: 128.0 m, O: 50.8 m, R: 25.6 m, I: 12.8 m

Illuminator Supplement Light Type IR Supplement Light Range Up to 10 m Smart Supplement Light Yes IR Wavelength 850 nm Video Main Stream

50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 24 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (704 × 576, 640 × 480)

60 Hz: 24 fps (704 × 480, 640 × 480)

Third Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

60 Hz: 24 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

Video Compression

Main stream: H.265/H.264,

Sub-stream: H.265/H.264/MJPEG,

Third stream: H.265/H.264

Video Bit Rate 32 Kbps to 8 Mbps H.264 Type Baseline Profile,Main Profile,High Profile H.265 Type Main Profile Bit Rate Control CBR,VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 4 fixed region(s) for each stream Target Cropping Yes Audio Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Environment Noise Filtering Yes Network Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets Simultaneous Live View Up to 20 channels API Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP User/Host

Up to 32 users

3 user levels: administrator, operator, and user

Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Con
