Hikvision D24F2 / D14F2 4MP 2.8MM WDR H.265+ POE IP67 Dome IP Camera

Camera Sensor 4 MP 1/2.5" CMOS Lens Mount M12 Focal Length 2.8mm Maximum Aperture f/2 Lens Field of View Horizontal: 102° Vertical: 53° Diagonal: 124° IR Cut Filter Mechanical Day/Night Yes Minimum Illumination Color: 0.028 Lux Shutter Speed 1/100,000 to 1/3 Seconds Camera Angle Adjustment Horizontal: 0 to 355° Vertical: 0 to 75°

Video Streaming Resolution 2560 x 1440 at 30 fps Supported Video Compression H.264, H.264+, H.265, H.265+, MJPEG Multi-View Streaming Yes, 3 Streams Automatic Gain Control Yes

Networking Security HTTPS, IEEE 802.1X, IP Address Filtering, Password Protection, Watermark Supported Protocols Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, PPPoE, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), TCP, UPnP

System Integration Application Programming Interface (API) ONVIF Profiles G & S, ISAPI Analytics Motion Detection Line Crossing Detection Intrusion Detection Face Detection Event Trigger Yes Event Action Recording, Notification, Alarm Data Streaming Yes

System Requirements Mobile Operating Systems iOS, Android

Environmental Operating Temperature -22 to 140°F / -30 to 60°C Operating Humidity 0 to 95% IP Rating IP67 IK Rating IK10

General Pan/Tilt None I/O Connections 1 x RJ45 1 x Power IR Illuminators 850 nm IR Range 100' / 30.48 m Video Management Software iVMS-4200, Hik-Connect Internal Storage None External Storage Options NAS Power Source DC, PoE 802.3af (15 W) Power Consumption DC: 7.5 W PoE: 9 W Material of Construction Metal (Unspecified Type), Plastic Dimensions ø: 4.4 x H: 3.2" / ø: 111.0 x H: 82.4 mm Weight 1.1 lb / 500 g

Packaging Info Package Weight 1.695 lb Box Dimensions (LxWxH) 5.4 x 5.2 x 4.4"
