Hikvision DS-3T0506HP-E/HS 4 Port Gigabit Unmanaged Harsh POE Switch

-3 × gigabit PoE port, 1 × gigabit Hi-PoE port, 2 × gigabit SFP fiber optical port.

-IEEE 802.3at/af/bt standard for Hi-PoE port (Max. 60 W PoE output).

-IEEE 802.3at/af standard for PoE ports (Max. 30 W PoE output).

-IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z and IEEE 802.3ab standard.

-6 kV surge protection for PoE ports.

-Up to 300 m long-range transmission.

-PoE watchdog to auto detect and restart the cameras that do not respond.

-Port isolation to improve network security.

-Wire-speed forwarding.

-Wider temperature (-30 °C to 65 °C) design.

-Store-and-forward switching.

-Solid high-strength metal shell.

-Reliable fan-free design.

General Shell Metal material, fan-free design Net Weight 0.38 kg (0.84 lb) Gross Weight 0.94 kg (2.07 lb) Dimensions (W × H × D) 158.0 mm × 101.2 mm × 31.6 mm (6.22'' × 3.98'' × 1.24'') Operating Temperature -30 °C to 65 °C (-22 °F to 149°F) Storage Temperature -40 °C to 85 °C (-40 °F to 185 °F) Operating Humidity 5% to 95% (no condensation) Relative Humidity 5% to 95% (no condensation) Power Supply 48VDC, 1.35A Max. Power Consumption 65 W Power Consumption in Idle 5 W Installation Mode Desk-Mounted,Rail Surge Protection 6 KV Network Parameters Ports 4 × Gigabit PoE port,2 × Gigabit fiber optical port MAC Address Table 2 K Switching Capacity 12 Gbps Packet Forwarding Rate 8.928 Mpps Internal Cache 1 Mbits PoE Power Supply PoE Standard IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt PoE Power Pin 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) PoE Port

Hi-PoE: Port 1

PoE: Ports 2 to 4

Max. Port Power

Port 1: 60 W

Ports 2 to 4: 30 W

PoE Power Budget 65 W Dialing Function Long Range

Ports 3 to 4: up to 300 m

Long range performance may vary depend on camera model or cable condition.

Port Isolation Ports 1 to 4: port isolation mode to improve network security. PoE Watchdog Ports 1 to 4: auto detect and restart the cameras that do not respond. Approval EMC FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015) Safety UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017) Chemistry CE-RoHS (2011/65/EU)
