ID: TL-DECO-M9 PLUS-3PACK
Specification
|
Expand group heading
Product Summary
|
|
|---|---|
|
Collapse group heading
Hardware Specifications
|
|
| Standards & Protocols |
IEEE 802.11 a/b/g/n/ac IEEE 802.3
IEEE 802.11 k/v/r
|
| Processors |
Quad-Core MHz
|
| Memory |
4 GB eMMC Flash and 512 MB RAM
|
| Wi-Fi Frequency & Signal Rate |
• 400 Mbps on 2.4 GHz
• 867 Mbps on 5 GHz-1
• 867 Mbps on 5 GHz-2 (Backhaul)
|
| Wi-Fi Chipset Features |
• Wi-Fi SON
• MU-MIMO
• TX Beamforming
|
| Antennas & Transmit Power |
Omnidirectional:
• 6 Wi-Fi Antennas
• 1 Bluetooth Antenna
• 1 ZigBee Antenna
|
| Ports & Connections |
• 2 x Gigabit Ethernet per Deco Unit
• 1 x USB 2.0 Port (Reserved)
|
| Buttons |
• Reset Button (Underneath)
|
| LED Panel |
• Single Multicolor LED
|
|
Product Dimensions (in)
(Width x Depth x Height)
|
Individual Unit:
5.7 in (Dia) x 1.82 in (H)
|
| Product Weight (lb) |
Individual Unit:
0.96 lb
|
|
Collapse group heading
Security Specifications
|
|
| Wi-Fi Security |
WPA2-Personal
|
| Firewall Features |
SPI Firewall
|
|
Collapse group heading
Mobile App Specifications
|
|
| Mobile App Name |
Deco
|
| System Requirements |
Android 4.3 or later iOS 8.0 or later
|
|
Collapse group heading
Other Specifications
|
|
| Power Requirements |
12V/2A
|
| Operating Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
|
| Regulatory Certifications |
CE
FCC: TE7M6
Bluetooth
RoHS
EAC
|
