- Gigabit Ethernet connections on all ports provide full speed of data transferring
- Integrated security strategy including 802.1Q VLAN, ACL, Port Security and Storm control help protect LAN area investment
- L2/L3/L4 QoS and IGMP snooping optimize voice and video applications
- WEB/CLI managed modes, SNMP, RMON bring abundant management features
- Innovative energy-efficient technology saves up to 65% of power consumption
Features
Layer 2 Features
- Static Link Aggregation/ Link Aggregation Control Protocol (LACP)
- Up to 512 VLANs simultaneously(out of 4K VLAN IDs)
- STP/RSTP/MSTP
- IGMP Snooping
Quality of Service
- 4 priority queues
- Support IEEE 802.1P
- DSCP QoS
- Rate limit feature
Security Strategies
- Access Control List (L2~L4 ACL)
- Port Security
- Storm Control
- SSL and SSH encryptions
Management
- Web-based GUI
- Command Line Interface(Telnet)
- SNMP v1/v2c/v3
- RMON (1, 2, 3, 9 group)
Specification
|
HARDWARE FEATURES |
|
|
Standards and Protocols |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, |
|
Interface |
8 10/100/1000Mbps RJ45 Ports |
|
Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
|
Fan Quantity |
Fanless |
|
Dimensions (W X D X H) |
8.2* 4.9* 1.0 in. (209* 126* 26mm) |
|
Power Supply |
100~240VAC, 50/60Hz |
|
Power Consumption |
Maximum: 6.42W (220V/50Hz) |
|
PERFORMANCE |
|
|
Bandwidth/Backplane |
16Gbps |
|
MAC Address Table |
8k |
|
Packet Forwarding Rate |
11.9Mpps |
|
Jumbo Frame |
9216 Bytes |
|
SOFTWARE FEATURES |
|
|
Quality of Service |
Support 802.1p CoS/DSCP priority |
|
L2 Features |
IGMP Snooping V1/V2/V3 |
|
VLAN |
Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs) |
|
Access Control List |
L2?L4 package filtering based on source and destination |
|
Security |
SSH v1/v2 |
|
Management |
Web-based GUI and CLI management |
|
OTHERS |
|
|
Certification |
CE, FCC, RoHS |
|
Package Contents |
TL-SG2008 |
|
System Requirements |
Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux. |
|
Environment |
Operating Temperature: 0?~40? (32?~104?); |
