1000ft 2C 22AWG Stranded Shielded Control Cable - CMP Plenum - White
Hurry up! Sales Ends In
Hurry! Only 5 Left in Stock!
This 2 conductor 22AWG stranded shielded control cable is white in color and 1000 feet in length. It is typically used in control panel and automation control applications.
| Physical Characteristics | |
|---|---|
| Cable Lengths Available | 1000 foot [305m] Pull Box |
| Color (jacket) | White |
| Number of Conductors | 2 Conductors (Red/Black) |
| Jacket Material | PVC - Polyvinyl Chloride |
| Conductors Construction | 7/.0.01'' (7/0.254mm) |
| Nominal Jacket Thickness | 0.018'' (0.46mm) |
| Minimum Spot | 0.014'' (0.36mm) |
| Jacket Outer Diameter | 0.145''±0.006'' (3.7±0.15mm) |
| Insulation Material | PVC - Polyvinyl Chloride |
| Insulation Outer Diameter | 0.0452''±0.004'' (1.15±0.10mm) |
| Wire Gauge | 22 AWG |
| Maximum Voltage | 300V |
| Material (conductors) | Bare Copper |
| Ripcord | DuPont Kevlar® |
| Shielding | 100% AL-Mylar & PET Coverage with 25% Overlapping |
| Drain Wire | 24 AWG Stranded Tinned Copper |
| Conductor Resistance | 16.89 Ohms/1000 FT. 55.4 Ohms/Km |
| Operating Temperature | -20℃ ~ +75℃ |
| Approvals | |
| c(ETL)us | Compliant |
| Environmental | |
| RoHS | Compliant |
| Packaging Information | |
| Package Quantity | 1 Pull Box |
| Product Weight | 22.53 lbs |
