1. support 8 HDMI signal input and 8 HDMI signal output
2. support reasolution up to 4Kx2K@30Hz
3. Transmission data rate up to 10.2Gpds
4. support IR remote control
5. support RS232 control
6. support 3D
7. pure hardware design, plug and play
8. support button control for switching inputs/poutputs.
HDMI signal: HDMI 1.4 full compatible with HDCP1.4
Input:8 HDMI
Output: 8 HDMI
Transmission rate: 10.2GBPS
support resolution: 480i@60Hz, 480p@60Hz, 576i@50Hz, 720p@50/60Hz, 1080i@50/60hz, 1080o@50/60hz, 4Kx2K@25/30Hz
support audio format: DTS-HD/Dolby-true HD/LPCM7.1/DTS/Dilby-AC3/DSD
TUV: 4:2:2
Video bandwidth: 340Mhz
HDMI port: type A19pin, female
RS232: RS232 serial control
Working temperature: 0c-60c
working humidity: 0-90%
power supply: DC12V/3A
power consumption: 27W(max)
Product dimension: 482.45x179.60x44.40 mm
weight: 2.07Kg
Package contents:
1x Matrix switch unit
1x DC12V/3A power adapter
1x User manaul
1x Remote controller
1x RS232 serial port cap
2x wall-mount kit
