Product specification
Cat5e. U/UTP. 4×2×0.50mm
CMP(UL)
Executive Standard
ISO/IEC11801 ED.2
ANSI/TIA-568-C.2
Conductor
Material
Solid-Bare Copper
AWG
24
Nom.O.D.(mm)
0.50±0.02 mm
DC resistance
≤95 Ω/km
Insulation
Material
FEP
Thickness
0.2±0.02 mm
Diameter
0.85±0.04 mm
Color
Blue/White- Blue
Green/White-Green
Orange
/White-Orange
Brown/White-Brown
Pitch
Offset pitch
≤25 mm
Cable pitch
≤140 mm
Sheath
Material
PVC (UL CMP)
External O.D.
4.9±0.02 mm
Color
Gray(RAL7046)
Tensile strength
>13.5 Mpa
Thickness
0.45±0.03 mm
Surface Printing
Letter height
3.0±0.3 mm
Color
Black
Print error
& Space
1±0.005 m
Case number
Yes
Packing
Packing
Carton
Once packing dimension
350mm*216mm*350mm
Twice packing dimension
370mm*460mm*370mm
Twice packing quantity
2 cases
Packing length
305±1 m
Rip-cord
Yes
Ambient temperature
-20℃～60℃
