-Up to 8-ch IP camera inputs, plug & play with 8 power-over-Ethernet (PoE) interfaces
-H.265+/H.265/H.264+/H.264 video formats
-Up to 2-ch@12 MP or 3-ch@8 MP or 6-ch@4 MP or 12-ch@1080p decoding capacity
-Up to 80 Mbps incoming bandwidth
-Adopt Hikvision Acusense technology to minimize manual effort and security costs
| Number of Channels |
8
|
| Playback Resolution |
HDMI: 3840 x 2160 at 30 Hz 2560 x 1440 at 60 Hz VGA: 1920 x 1080 at 60 Hz
|
| Recording Resolution |
1080p, 720p, 4CIF, 2CIF, DCIF, QCIF, CIF, UXGA, VGA, 3 MP, 4 MP, 5 MP, 6 MP, 8 MP, 12 MP
|
| PTZ Support |
Yes
|
| Throughput |
80 Mb/s (Incoming) 160 Mb/s (Outgoing)
|
| A/V I/O |
1x HDMI 1x VGA 1x RCA Audio Output (2 V p-p, 1 Kilohm) 1x RCA Audio Input (1 Kilohm, Linear)
|
| Communication I/O |
1x RJ45 Gigabit Ethernet 8x RJ45 10/100 Mb/s Ethernet PoE 3x USB-A 2.0
|
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Installed Drive |
No
|
| Mobile App Compatible |
Yes: Android & iOS App Name: Hik-Connect
|
| PoE Power Budget |
80 W
|
General
| Number of Channels |
8
|
| Playback Resolution |
HDMI: 3840 x 2160 at 30 Hz 2560 x 1440 at 60 Hz VGA: 1920 x 1080 at 60 Hz
|
| Recording Resolution |
1080p, 720p, 4CIF, 2CIF, DCIF, QCIF, CIF, UXGA, VGA, 3 MP, 4 MP, 5 MP, 6 MP, 8 MP, 12 MP
|
| PTZ Support |
Yes
|
| Throughput |
80 Mb/s (Incoming) 160 Mb/s (Outgoing)
|
| IP Camera Support |
8
|
| Decoding Resolution |
1 Channel: 12 MP at 30 fps 2 Channels: 8 MP, 12 MP at 30 fps 3 Channels: 8 MP at 30 fps 4 Channels: 4 MP at 30 fps 6 Channels: 4 MP at 30 fps 8 Channels: 1080p at 30 fps
|
| 2-Way Audio |
Yes
|
Connectivity
| A/V I/O |
1x HDMI 1x VGA 1x RCA Audio Output (2 V p-p, 1 Kilohm) 1x RCA Audio Input (1 Kilohm, Linear)
|
| Communication I/O |
1x RJ45 Gigabit Ethernet 8x RJ45 10/100 Mb/s Ethernet PoE 3x USB-A 2.0
|
| Audio I/O |
1x Input 1x Output
|
| System Connection |
2x SATA
|
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Remote Connections |
128
|
| Network Protocols |
DDNS, DHCP, DNS, HTTP, HTTPS, IPv4, IPv6, NFS, NTP, RTSP, SADP, SMTP, SNMP, TCP/IP, TLS, UPnP, iSCSI
|
Compatibility
| Supported Video Codecs |
H.264, H.264+, H.265, H.265+
|
| Supported Audio Codecs |
AAC, G.711A, G.711U, G.722, G.726
|
| Supported IEEE Standards |
802.3af (PoE 15.4 W), 802.3at (PoE+ 30 W)
|
System
| Installed Drive |
No
|
| Max Capacity Supported |
10 TB (Each Drive) 20 TB (Total)
|
| Number of Bays |
2x Internal
|
Software System Requirements
| OS Compatibility |
Android/iOS
|
| Mobile App Compatible |
Yes: Android & iOS App Name: Hik-Connect
|
Notifications
| Alarm I/O |
4x Input 1x Output
|
| Event Trigger |
Analytics, Motion
|
System Functions
| Search Modes |
Smart Search
|
| Recording Modes |
Analytics
|
| Fisheye Dewarping |
No
|
Electrical
| Power Consumption |
15 W (Without HDD)
|
| Power Supply Type |
External
|
| PoE Power Budget |
80 W
|
Physical
| Built-In Display |
No
|
| Operating Conditions |
14 to 131°F / -10 to 55°C at 10 to 90% Humidity
|
| Certifications |
CE, FCC
|
| LED Indicators |
Yes
|
| Dimensions (W x D x H) |
15.2 x 12.4 x 2.0" / 385.0 x 315.0 x 52.0 mm
|
| Weight |
6.6 lb / 3 kg (Without HDD)
|
Packaging Info
| Package Weight |
7.165 lb
|
| Box Dimensions (LxWxH) |
17.1 x 15.3 x 5.8"
|
