Specifications
| Physical Characteristics | |
|---|---|
| Cable Length | 1000ft [305m] |
| Cable Diameter | 6.60 mm |
| Number of Pairs | 4 Pairs |
| Color of Pairs | White-Blue White-Green White-Orange White-Brown |
| Wire Gauge | 24AWG Solid |
| Conductor Material | 100% Bare Copper |
| Conductor Outer Diameter | 0.5 + 0.03mm |
| Jacket Material | PVC - Polyvinyl Chloride |
| Outer Jacket Diameter | 6.6 + 0.2mm |
| Outer Jacket Average Thickness | 0.55mm Above |
| Stranding Count & Diameter |
1/24mm |
| Jacket Rating | CMR/FT4 [Riser Rated] |
| Insulator Material | HD-PE |
| Insulator Diameter | 1.05 + 0.03mm |
| Insulator Average Thickness | 0.20 + 0.02mm |
| Cable Shielding | 100% Aluminum Foil Shield |
| Shielding AL/Pet Tape | 0.050 x 22mm |
| Shielding Drain Wire | 1/0.5mm (Tinned copper) |
| Rip Cord |
Yes - Nylon |
| Temperature Rating | 75ºC |
| Approvals | |
| UL | Yes |
| CSA | Yes |
| Environmental | |
| RoHS | Yes |
| Packaging Information | |
| Package Quantity | 1 |
|
Product Weight |
30.9lbs [14kg] |
