- 32CH 1080P NVR
- Third-party Network Cameras Supported
- Up to 6 Megapixel Resolution Recording
- HDMI and VGA output at up to 1920×1080P resolution
- 16-ch simultaneous playback
- HDD quota and group management
- 16 independent PoE network interfaces
Features
iOS, Android System Apps: Guarding Expert
- 32 Channel Network Video Recorder
- Video Input: 32CH IP@200Mbps
- Video Output: BNC, VGA, HDMI up to 1920x1080P
- Pentaplex Operation: Record, Playback, Backup, Live & Remote Access
- Recording Resolution: Up to 6MP (3072x2048)
- Recording Mode: Manual, Schedule, Video Detection, Motion Detection, Video Loss, Stop
- Playback Channel: 16CH
- Playback Resolution: Up to 6MP (3072x2048)
- Audio In/Out: 1CH/ 2CH, BNC
- Alarm In/Out: 16/4
- Built-in PoE: 16CH
- Network: 10/100/1000M
- Storage: 4 SATA up to 32TB
- 3 USB 2.0, eSATA, Support NAS, IP SAN
- Support POS #: 8
- Backup: USB, NAS, or eSATA, DVD-RW
Specification
|
Model |
N5332-P16 |
|
Video/Audio Input |
|
|
IP video input |
32 CH |
|
Two-way audio input |
1-ch, BNC (2.0 Vp-p, 1KΩ) |
|
Network |
|
|
Incoming bandwidth |
200Mbps |
|
Outgoing bandwidth |
160Mbps |
|
Remote Connections |
128 |
|
Video/Audio output |
|
|
Recording resolution |
6MP /3MP / 1080P / UXGA / 720P / VGA / 4CIF / 2CIF / CIF / QCIF |
|
Frame Rate |
Main Stream: 30 fps |
|
Sub Stream: 30 fps |
|
|
CVBS output |
1-ch, BNC (1.0 Vp-p, 75Ω) |
|
Resolution: 704 × 480 (NTSC) |
|
|
HDMI /VGA output |
1-ch, resolution: |
|
Audio Output |
2-CH, BNC (Linear, 600Ω) |
|
Decoding |
|
|
Live view / Playback resolution |
6MP /3MP / 1080P / UXGA / 720P / VGA / 4CIF / 2CIF / CIF / QCIF |
|
Capability |
16 CH @ 720P, 16 CH @ 1080P |
|
Hard Disk |
|
|
SATA |
4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs |
|
eSATA |
1 eSATA interfaces |
|
Capacity |
Up to 8 TB for each disk |
|
External Interface |
|
|
Network Interface |
1 x 10/100/1000 Mbps self-adaptive Ethernet interface |
|
Serial interface |
RS-232; RS-485; Keyboard |
|
USB Port |
3 x USB2.0 |
|
Alarm in/out |
16 / 4 |
|
POE |
|
|
Interface |
16 independent 100 Mbps PoE network interfaces |
|
Max. Power |
200W |
|
Supported Standard |
AF and AT |
|
Others |
|
|
Power Supply |
100 ~ 240v AC, 6.3A |
|
Power Consumption |
≤ 45W |
|
Working Temperature / Humidity |
14F ~ 131F / -10C ~ 55C |
|
Chassis |
19" rach-mounted 1.5U chassis |
|
Dimensions |
17.5" x 15.3" x 2.8" (445 x 390 x 70mm) |
|
Weight |
≤8.8 lb (4 Kg) (without hard disk or DVD-R/W) |
|
Apps |
|
|
iOS, Android Apps: |
Guarding Expert |
|
Brand Warranty |
2 Years |
Warranty
Modcom IT Solutions:
1 Year
